Specification
Flow rate
Suction
strainers are available from a flow rate of 5 to 250 lpm.
Nominal particle rating
Filters are available from
10 microns to 150 microns filtration rating
Filter
caps
Die cast aluminium nut and caps are installed
Filter media
Stainless steel wire mesh and perforated steel core.
Sealant
Epoxy based
Sizes
Custom build sizes are offered
Operating conditions
Filter can withstand temperature up to 120 ºC. Filter is washable or can be cleaned by
applying air pressure and reused.
Application:-
ENVIRO TECH suction strainer filters are most suited for filtration
of:
petroleum-based hydraulic fluids,
phosphate esters,
water glycols,
lubricating oils,
coolants,
fuels and water in fluid reservoirs,
sumps and similar
applications.
They are widely used in automobile, molding and allied engineering
industries.
